Good quality for all procelain ,ceramic tiles,glass...cutting
Reliable cutting performance : for fine stoneware, ceramic tiles and procelain are all available.
Good cutting speed with clean cutting edges
Its price is much competitive to meet general market demand .
The size we can do from 75mm to 400mm
Below size for reference first ,the real size we can do it as per customer's special demand .
Products code |
Diamater |
Arbor | Size of segment | ||
|---|---|---|---|---|---|
| (mm) | Thick (mm) | Width(mm) | |||
| BYCTILE03-C | 3" | 75mm | 20 | 1 | 5/10 |
| BYCTILE04-C | 4" | 105mm | 20 | 1.1 | 5/10 |
| BYCTILE4.3-C | 4.3" | 110mm | 20 | 1.2 | 5/10 |
| BYCTILE4.5-C | 4.5" | 115mm | 22.23 | 1.4 | 5/10 |
| BYCTILE05-C | 5" | 125mm | 22.23 | 1.5 | 5/10 |
| BYCTILE06-C | 6" | 150mm | 22.23 | 1.6 | 5/10 |
| BYCTILE07-C | 7" | 180mm | 22.23 | 1.8 | 5/10 |
| BYCTILE08-C | 8" | 200mm | 22.23 | 2.0 | 5/10 |
| BYCTILE09-C | 9" | 230mm | 22.23 | 2.2 | 5/10 |
| BYCTILE10-C | 10" | 250mm | 25.4 | 2.4 | 10 |
| BYCTILE12-C | 12" | 300mm | 20/50 | 2.5 | 10 |
| BYCTILE14-C | 14" | 350mm | 20/50 | 3.0 | 10 |
| BYCTILE16-C | 16" | 400mm | 20/50 | 3.4 | 10 |
| ▲Different arbor sizes and segment specification are available up on detail request | |||||
